Small ecological footprint
- Minimized water and gum usage
- Significantly reduced waste
- Energy-friendly
The clean-out units Azura CX 85, CX 125 and CX 150 are showpieces of ECO3’s expertise. Their cascading clean-out technology enables you to handle more plates, with lower waste costs. The pH-neutral water-based gum circulates between two shallow trays, which raises the clean-out efficiency and reduces gum consumption. It also lengthens the bath life up to 7,000 m2.
Choose your model: connected online with the platesetter or stand-alone. There’s no need for a developer or replenisher and everything is pre-set. So once the Azura CX clean-out unit is installed, you’re good to go: the unit is designed to handle up to 50,000 m2 of plates a year!
-
-
Easy to use
- Low maintenance
- State-of-the-art interface
Cascading clean-out technology
Main features
- Simplified clean-out step eliminates many process variables (temperature, pH, conductivity, dwell time, replenishment etc.)
- Operates in daylight, always fully functional
- State-of-the-art interface
| Azura CX 85 | Azura CX 125 | Azura CX 150 | |
|---|---|---|---|
| Plates | Azura TU, Azura TS | Azura TU, Azura TS | Azura TU, Azura TS |
| Plate type | Chemistry-free thermal offset plates | Chemistry-free thermal offset plates | Chemistry-free thermal offset plates |
| Plate width, min.-max. | 200-850 mm (7.9-33.5”) | 200-1250 mm (7.9-49.2”) | 400-1500 mm (15.7-59.0”) |
| Plate length, min. | 275 mm (10.9”) | 275 mm (10.9”) | 400 mm (15.7”) |
| Plate thickness, min.-max. | 0.15-0.30 mm (0.006-0.012”) | 0.15-0.30 mm (0.006-0.012”) | 0.15-0.40 mm (0.006-0.015”) |
| Consumption | Water: 7 ml/m² | Water: 8 ml/m² | Water: 9ml/m² |
| Gum: 20 ml/m² | Gum: 25 ml/m² | Gum: 30 ml/m² | |
| Plate speed | 160 cm/min | 160 cm/min | 160 cm/min |
| Plate throughput (interdistance: 400 mm) | 95 plates/h (landscape 745 x 605 mm) | 95 plates/h (landscape 745 x 605 mm) | 80 plates/h (landscape 1030 x 790 mm) |
| 67 plates/h (portrait 1030 x 790 mm) | 80 plates/h (landscape 1030 x 790 mm) | 49 plates/h (portrait 1524 x 1143) | |
| Plate volume | Up to 50,000 m²/year | Up to 50,000 m²/y | Up to 50,000 m²/y |
| Dryer temperature | 35-55°C (95-131°F) | 35-55°C (95-131°F) | 35-55°C (95-131°F) |
| Max. noise emission | < 70 dB | < 70 dB | < 70 dB |
| Dimensions (width, length) | 1424 x 942 mm (56.0 x 37.1”) | 1824 x 942 mm (71.8 x 37.1”) | 2074 x 942 mm (81.7 x 37.1”) |
| Electrical specifications EUR | Single-phase: 1W + N + PE 230V / 8.4 Amps, 50/60Hz. | Single-phase: 1W + N + PE 230V / 8.4 Amps, 50/60Hz. | Single-phase: 1W + N + PE 230V / 8.4 Amps, 50/60Hz. |
| Electrical specifications US | Single-phase: 2W + PE 208 – 230V / 8.4 Amps, 50/60Hz. | Single-phase: 2W + PE 208 – 230V / 8.4 Amps, 50/60Hz. | Single-phase: 2W + PE 208 – 230V / 8.4 Amps, 50/60Hz. |
| Power EUR/US | 1.9 kW | 1.9 kW | 1.9 kW |
| Approvals | CE standards – cTÜV – US certification | CE standards – cTÜV – US certification | CE standards – cTÜV – US certification |
| Accessories | Feed table / Exit table / Drip tray | Feed table / Exit table / Drip tray | Feed table / Exit table / Drip tray |
| Interface for platesetters | Included for all ECO3 platesetters | Included for all ECO3 platesetters | Included for all ECO3 platesetters |
| Optional for third-party platesetters | Optional for third-party platesetters | Optional for third-party platesetters |
